Cat6a STP keystone jack

Model: FLT-61001
Place of Origin: Zhejiang,China (Mainland)

inquiry

basketAdd to Basket  Edit

Share |

Product Description

Payment & Shipping Terms
Unit Price:0.3~0.5 USD
Payment Terms:T/T
Min. Order:1000 Piece/Pieces
Means of Transport:Ocean, Air


  • Contact material: phosphor bronze stamping pin at thickness of 0.35mm

  • Contact mating area plating material: gold plating option (3U/6U/15U/30U/50U") over nickel

  • PCB material: FR-4, T=1.6mm

  • IDC contact material: phosphor bronze at thickness of 0.5mm and nickel plating

  • Housing color: ivory

  • Housing materials: ABS or PC

  • Housing flammability rating: UL 94V-0

  • Workable wire gauge range: AWG 22~26

  • Industry standards:

  • RoHS compliant

  • TIA/CAT6, or CAT5E or CAT3

  • 568A/568B


Category: others
